Product Summary
The TMPZ84C011AF-6 is a high-performance CMOS 8-bit microprocessor that contains the functional peripherals such as counter timer circuit 9CTC) parallel I/O port, and clock generator/controller around the TLCS-Z80 MPU. TMPZ84C011AF-6 has many I/O ports, making it available for a wide range of system applications such as the controller, the measuring instrument, and the word processor.
Parametrics
TMPZ84C011AF-6 absolute maximum ratings: (1)Input low voltage: -0.3 to 0.2V; (2)Input high voltage: VCC-0.2 TO VCC+0.3 V; (3)Output low voltage, IOL=1.2 mA: 0.4 max.V; (4)Output high voltage, IOL=-0.7 mA: 2.2 min.V; (5)Input leakage current, vss≤vin≤vcc: ±2μA; (6)3-state output leakage current in float, vss≤vout≤vcc: ±2μA; (7)Power supply current: 10 max. mA; (8)Stand-by supply current: 10 max.μA.
Features
TMPZ84C011AF-6 features: (1)Built-in MPU, CTC and CGC functions of TLCS-Z80 family; (2)High speed operation(6MHZ operation); (3)Built-in clock generator (CGC, clock generator/controller); (4)Built-in standby capability(with the controller built in); (5)Low power consumption: operation, 15mA typ.(4MHZ) 22mA typ.(6MHZ); idle, 1.0 mA typ.((4MHZ) 1.5mA typ.(6MHZ); standby, 500 nA typ.; (6)Wide operational power voltage range(5V±10%, 3 to 6V operation supported); (7)Wide operational temperature range(-40 to +85 ℃); (8)Many general-purpose ports(5 pots, 40 bits) which support I/O operation on a bit basis; (9)Four channels of timer/counter (the same capability as the TLCS-Z80 CTC); (10)Built-in dynamic RAM refresh controller; (11)Daisy-chain interrupt control pin; (12)Housed in a compact 1---pin mini-flat package.
Diagrams
 |
