Product Summary

The C1701C is a bipolar analog integrated circuit.

Parametrics

C1701C absolute maximum ratings: (1)Vs: -8.0V; (2)Is: -40mA; (3)Isyn: 5.0mA; (4)Tj: 125℃; (5)Topt: -20 to 70℃; (6)P: 350mW.

Diagrams

C1701C diagram
